Advanced Lead-acid Battery Formation Equipment MCIF Plus Series

MCIF Plus Series:Advanced Lead - acid Battery Formation Equipment

MCI-200F/MCIF-Plus
Battery Cycler Intro

MCIF Plus Series: Advanced Lead-acid Battery Formation Equipment
Suitable for large-scale and economical production of lead-acid batteries,
Support a variety of series and parallel connected batteries manufacturer and high-efficiency energy consumption.
MCIF Plus Series owns single-cell voltage and temperature measurement features,
intuitive touchscreen makes MCIF Plus Series has both PC and panel dual-mode operations.
With built-in memory modules,
MCIF Plus Series is able to store more than 24 hours of test data without being connected to a PC.
The comprehensive of MCIF Plus Series no longer need to provide an extra controller and related electronic equipment.
Through the latest generation of communication protocols, MCIF Plus Series is compatible with the latest PC models。

  • configurable display Information.
  • Customized system construction and data analysis.
null
Dual control modes
null
Touch operation
ModelMCIF Plus Series
AC PowerCustomized According To Client Needs
Loading Range
Charge
Discharge

6 ~300V
6 ~270V
Constant Voltage
Maximum
Resolusion
Accuracy

300V
0.01V
±0.5% F.S.
Constant Current
Maximum
Resolusion
Accuracy

Depend on Spec*
16 bit
±0.5% F.S.
Data Recording Time1s
Data Storage MethodUSB
Communication InterfaceEthernet
Ambient23°C±2°C; 20~90 HR

*Accept customized request

ModelVoltage(V)Current (A)
MCIF Plus 300V/5A3005
MCIF Plus 300V/10A30010
MCIF Plus 300V/30A30030
MCIF Plus 300V/50A30050
MCIF Plus 300V/60A30060
MCIF Plus 300V/100A300100
